Securefold Bottom Rolling

Bottom rolling system for folding doors weighing up to 80kg

  • For folding wooden doors weighing up to 80kg
  • Ideal for applications where top hung structural support is limited
  • Available in a number of door configurations - up to 6 doors folding to one side
  • 2 hinge types available - mortice or non mortice
  • Extremely robust and corrosion resistance - all components are made from 316 stainless steel
  • Available in four stunning finishes - satin, chrome, black and gold
  • Optional locking system available as an alternative to flush bolts

Catering for wooden folding doors weighing up to 80kg, Securefold Bottom Rolling allows for huge flexibility in terms of the type of applications it can cater for.

Bottom Rolling Technology

Securefold Bottom Rolling has been designed using bottom rolling technology to allow the weight of the doors to be carried by the floor. Ideal for applications where there is limited overhead support such as orangeries, conservatories, out buildings and extensions, Securefold Bottom Rolling eliminates the need for a large upper beam.

Wide Range of Door Configurations

The system can be specified for a wide range of doors configurations – catering for up to 6 doors folding to one side.

Extremely Robust and Corrosion Resistant

Manufacture from 316 marine grade stainless steel, Securefold Bottom Rolling is extremely robust and resistant against corrosive elements making the system ideal for coastal properties.

Four Stunning Finishes

Securefold Bottom Rolling is available in four stunning finishes – satin, chrome, polished brass or black – to suit a wide range of décor schemes.

Two Hinge Types

The system is available in mortice and non mortice hinge types to allow for flexibility of installation.

Product Max. Door Height Max. Door Width Door Thickness Range Max. Door Weight Door Material  Application
Securefold Bottom Rolling 3000mm 1000mm 56 - 68mm 80kg Wood Interior/Exterior



Name File Size
Securefold Brochure 6.89mb DOWNLOAD
Securefold Bottom Rolling Datasheet 703.02kb DOWNLOAD
Securefold Bottom Rolling Fitting Instructions 1.21mb DOWNLOAD
Securefold Bottom Rolling Non Mortice Fitting Instructions 1.31mb DOWNLOAD
